HONDA VERTICAL SHAFT V-TWIN 20.8HP 1" SHAFT ES

HONDA VERTICAL SHAFT V-TWIN 20.8HP 1″ SHAFT ES

Code: .NGXV630R-QAF

HONDA VERTICAL SHAFT V-TWIN 20.8HP 1″ SHAFT ES

$2,210.00

Out of stock

Share (0)
Total: 0 Total: 0 Total: 0 Total: 0

Description


   Honda GXV630 Vert shaft e-start

SPECIFICATIONS

MODEL GXV630
TYPE Air-cooled 4-stroke OHV petrol engine, 90° V-twin design,
vertical shaft
BORE & STROKE 2 / 78 x 72 mm
DISPLACEMENT 688 cm3
COMPRESSION RATIO 9.3:1
NET POWER 15.5 kW (20.8 HP) / 3 600 rpm
CONTINUOUS RATED POWER 10.5 kW (14.1 HP) / 3 000 rpm
MAXIMUM NET TORQUE 48.3 Nm / 4.93 kgfm / 2 500 rpm
IGNITION SYSTEM Digital CDI with variable ignition timing
STARTING SYSTEM Electric Start
COOLING SYSTEM Forced-Air
FUEL CONSUMPTION AT RATED POWER 5.0 L/h at 3,600 rpm
RECOMMENDED FUEL Unleaded
LUBRICATION SYSTEM Full-pressure
OIL CAPACITY 2.2l
DIMENSIONS 449 x 420 x 475 mm
DRY WEIGHT 46.5kg
